Quick Specs - Louvers
| Name | A445 |
|---|---|
| Specifier Name(s) | A445 |
| Avaliability | Available |
| Free Area | 8.16 SqFt, 51.00%, 51.00(calc) |
| Blade Angle | 45° |
| Name | Straight Blade (J-Blade) |
| Material Options | Extruded Aluminum, or Extruded Aluminum 6063 Alloy |
| Blade Orientation | Horizontal |
| Drainable Blade | Yes |
| Panel Minimum Size(s) | W: 12"x H: 12" |
| Panel Maximum Size(s) | W: 120"x H: 120" |
| Pressure Drop | .19 in. w.g. @ 1000 fpm |
| Water Penetration (fpm) | 1021 (fpm) |
Detailed Specs
*For additional options/configurations see spec sheet or contact the factory.
*This info listed here is For Reference ONLY, Please Refer to the Submittal For Full Product Data
