Blade Type - Air Balance

Single Thickness Blade

Minimize leakage and maximize air performance. Single thickness blades have a thin yet sturdy profile that minimizes the impact on the air stream. Add blade seals for tight closure with minimal air leakage when the unit closes.

Single thickness blades are available for standard control dampers, backdraft dampers, and round dampers.

Looking for something more

Specific?

Try our product filtering tool here!

Filter Products

A70

7.5" Deep Round Galvanized Steel Damper

A70

Maximum Velocity (FPM): 2000 fpm
Max Static Pressure: 4 .in w.g. @ 1000 fpm
Pressure Drop: .012 in. w.g. @ 1000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Single
Frame Shape: Round
Pressure Drop: .012 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Temperature Rating (°F): -35 °F to 180 °F

A70GL

7.5" Deep Round Galvanized Steel Damper with Honeywell Actuator

A70GL

Maximum Velocity (FPM): 1500 fpm
Max Static Pressure: 1 .in w.g. @ 1000 fpm
Pressure Drop: .012 in. w.g. @ 1000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Single
Frame Shape: Round
Pressure Drop: .012 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 1500 fpm (FPM)
Temperature Rating (°F): 250 °F

A70R

7.625" Deep Round Single Blade Galvanized Steel Damper with Nine Position Locking Hand Quadrant

A70R

Maximum Velocity (FPM): 1500 fpm
Max Static Pressure: 1 .in w.g. @ 1000 fpm
Pressure Drop: .012 in. w.g. @ 1000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Single
Frame Shape: Round
Pressure Drop: .012 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 1500 fpm (FPM)
Temperature Rating (°F): 250 °F

A75

7.5" Deep Round Aluminum Damper

A75

Maximum Velocity (FPM): 2000 fpm
Max Static Pressure: 4 .in w.g. @ 1000 fpm
Pressure Drop: .012 in. w.g. @ 1000 fpm

Material Options: Extruded Aluminum
Blade Type: Single Thickness Blade
Blade Action: Single
Frame Shape: Round
Pressure Drop: .012 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Temperature Rating (°F): -35 °F to 180 °F

A80

7.5" Deep Round Stainless Steel Damper

A80

Maximum Velocity (FPM): 2000 fpm
Max Static Pressure: 4 .in w.g. @ 1000 fpm
Pressure Drop: .012 in. w.g. @ 1000 fpm

Material Options: 304 Stainless Steel, or 316 Stainless Steel
Blade Type: Single Thickness Blade
Blade Action: Single
Frame Shape: Round
Pressure Drop: .012 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Temperature Rating (°F): -35 °F to 180 °F

AC111

4" Deep Single Blade Volume Control Balancing Damper

AC111

Maximum Velocity (FPM): 1500 fpm
Max Static Pressure: 1 .in w.g. @ 1000 fpm
Pressure Drop: .037 in. w.g. @ 1000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Single
Pressure Drop: .037 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 1500 fpm (FPM)
Temperature Rating (°F): 250 °F

A182

4" Deep Single Thickness Blade Stainless Steel Control Damper

A182

Maximum Velocity (FPM): 2000 fpm
Max Static Pressure: 4 .in w.g. @ 1000 fpm
Pressure Drop: .037 in. w.g. @ 1000 fpm

Material Options: 304 Stainless Steel, or 316 Stainless Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel / Opposed
Pressure Drop: .037 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Temperature Rating (°F): -40 °F to 180 °F

AC112

Round Single Blade Volume Control Damper

AC112

Maximum Velocity (FPM): 1500 fpm
Max Static Pressure: 1 .in w.g. @ 1000 fpm
Pressure Drop: .012 in. w.g. @ 1000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Single
Frame Shape: Round
Pressure Drop: .012 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 1500 fpm (FPM)
Temperature Rating (°F): 250 °F

A225-B

2" Deep Light Duty Aluminum Pressure Relief Backdraft Damper

A225B

Maximum Velocity (FPM): 1000 fpm
Max Static Pressure: 1 .in w.g. @ 1000 fpm
Pressure Drop: .14 in. w.g. @ 1000 fpm

Material Options: Extruded Aluminum, or Extruded Aluminum 6063 Alloy
Blade Type: Single Thickness Blade
Blade Action: Parallel
Pressure Drop: .14 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 1000 fpm (FPM)
Temperature Rating (°F): -40 °F to 180 °F

A260DW

Dual Wall Insulated Round Single Blade Volume Control Damper

A260DW

Maximum Velocity (FPM): 3000 fpm
Max Static Pressure: 6 .in w.g. @ 1000 fpm
Pressure Drop: .012 in. w.g. @ 1000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Single
Frame Shape: Round
Pressure Drop: .012 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 3000 fpm (FPM)

AC411

8" Deep Light Industrial Single Thickness Control Damper

AC411

Maximum Velocity (FPM): 4000 fpm
Max Static Pressure: 5 .in w.g. @ 1000 fpm
Pressure Drop: .017 in. w.g. @ 1000 fpm

Material Options: 304 Stainless Steel, 316 Stainless Steel, or Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel / Opposed
Pressure Drop: .017 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 4000 fpm (FPM)
Temperature Rating (°F): 250 °F

AC412

8" Deep Light Duty Industrial Galvanized Damper

AC412

Maximum Velocity (FPM): 4000 fpm
Max Static Pressure: 10 .in w.g. @ 1000 fpm
Pressure Drop: .017 in. w.g. @ 1000 fpm

Material Options: 304 Stainless Steel, 316 Stainless Steel, or Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel / Opposed
Pressure Drop: .017 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 4000 fpm (FPM)
Temperature Rating (°F): 250 °F

A335

2" Deep Aluminum Backdraft Damper

A335

Maximum Velocity (FPM): 3000 fpm
Max Static Pressure: 1 .in w.g. @ 1000 fpm
Pressure Drop: .35 in. w.g. @ 1000 fpm

Material Options: Extruded Aluminum, or Extruded Aluminum 6063 Alloy
Blade Type: Single Thickness Blade
Blade Action: Parallel
Pressure Drop: .35 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 3000 fpm (FPM)
Temperature Rating (°F): -40 °F to 190 °F

354

6" to 8" Deep Double Deck Multi-Zone Damper

Maximum Velocity (FPM): 1000 fpm
Max Static Pressure: 2 .in w.g. @ 1000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel / Opposed
Frame Shape: Rectangular
Maximum Velocity (FPM): 1000 fpm (FPM)
Temperature Rating (°F): -40 °F to 180 °F

356

10" Deep Triple Deck Multi-Zone Damper

Maximum Velocity (FPM): 1000 fpm
Max Static Pressure: 2 .in w.g. @ 1000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Maximum Velocity (FPM): 1000 fpm (FPM)
Temperature Rating (°F): -40 °F to 180 °F

BS66

4' Deep Galvanized Steel Backdraft Damper - Intake or Discharge

BS66

Maximum Velocity (FPM): 3000 fpm
Max Static Pressure: 4 .in w.g. @ 1000 fpm
Pressure Drop: .05 in. w.g. @ 1000 fpm

Material Options: 304 Stainless Steel, 316 Stainless Steel, or Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 3000 fpm (FPM)
Temperature Rating (°F): -30 °F to 180 °F

A388

Galvanized Steel Round Backdraft Damper

A388

Maximum Velocity (FPM): 3000 fpm
Max Static Pressure: 1 .in w.g. @ 1000 fpm
Pressure Drop: .05 in. w.g. @ 1000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Single
Frame Shape: Round
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 3000 fpm (FPM)
Temperature Rating (°F): -35 °F to 180 °F

A389

Aluminum Round Backdraft Damper

A389

Maximum Velocity (FPM): 3000 fpm
Max Static Pressure: 1 .in w.g. @ 1000 fpm
Pressure Drop: .05 in. w.g. @ 1000 fpm

Material Options: Extruded Aluminum
Blade Type: Single Thickness Blade
Blade Action: Single
Frame Shape: Round
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 3000 fpm (FPM)
Temperature Rating (°F): -35 °F to 180 °F

A390

Stainless Steel Round Backdraft Damper

A389

Maximum Velocity (FPM): 3000 fpm
Max Static Pressure: 1 .in w.g. @ 1000 fpm
Pressure Drop: .05 in. w.g. @ 1000 fpm

Material Options: 304 Stainless Steel, or 316 Stainless Steel
Blade Type: Single Thickness Blade
Blade Action: Single
Frame Shape: Round
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 3000 fpm (FPM)
Temperature Rating (°F): -35 °F to 180 °F

A395

4" Deep Single Thickness Blade Low Leakage Control Damper

A395

Maximum Velocity (FPM): 2000 fpm
Max Static Pressure: 4 .in w.g. @ 1000 fpm
Pressure Drop: .04 in. w.g. @ 1000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel / Opposed
Pressure Drop: .04 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Temperature Rating (°F): -40 °F to 180 °F

ID41

10" Deep Industrial Single Thickness Blade Control Damper

ID41

Maximum Velocity (FPM): 2500 fpm
Max Static Pressure: 6 .in w.g. @ 1000 fpm
Pressure Drop: .05 in. w.g. @ 1000 fpm

Material Options: 304 Stainless Steel, 316 Stainless Steel, or Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel / Opposed
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2500 fpm (FPM)
Temperature Rating (°F): 250 °F

ID42

10" Deep Industrial Single Thickness Blade Control Damper

ID42

Maximum Velocity (FPM): 2500 fpm
Max Static Pressure: 8 .in w.g. @ 1000 fpm
Pressure Drop: .05 in. w.g. @ 1000 fpm

Material Options: 304 Stainless Steel, 316 Stainless Steel, or Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel / Opposed
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2500 fpm (FPM)
Temperature Rating (°F): 250 °F

ID43

10" Deep Formed Steel Industrial Control Damper

ID43

Maximum Velocity (FPM): 2500 fpm
Max Static Pressure: 10 .in w.g. @ 1000 fpm
Pressure Drop: .05 in. w.g. @ 1000 fpm

Material Options: 304 Stainless Steel, 316 Stainless Steel, or Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel / Opposed
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2500 fpm (FPM)
Temperature Rating (°F): 250 °F

AC1

5.5" Deep Single Thickness Blade Control Damper (Parallel)

AC1

Maximum Velocity (FPM): 2000 fpm
Max Static Pressure: 4 .in w.g. @ 1000 fpm
Pressure Drop: .03 in. w.g. @ 1000 fpm

Material Options: 304 Stainless Steel, or Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Pressure Drop: .03 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Temperature Rating (°F): 200 °F

AC2

5.5" Deep Single Thickness Blade Control Damper (Opposed)

AC2

Maximum Velocity (FPM): 2000 fpm
Max Static Pressure: 4 .in w.g. @ 1000 fpm
Pressure Drop: .03 in. w.g. @ 1000 fpm

Material Options: 304 Stainless Steel, or Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Opposed
Pressure Drop: .03 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Temperature Rating (°F): 200 °F

BSL

2" Deep Light Duty Aluminum Pressure Relief Damper

BSL

Maximum Velocity (FPM): 1000 fpm
Max Static Pressure: 1 .in w.g. @ 1000 fpm
Pressure Drop: .075 in. w.g. @ 1000 fpm

Material Options: Extruded Aluminum, or Extruded Aluminum 6063 Alloy
Blade Type: Single Thickness Blade
Blade Action: Parallel
Pressure Drop: .075 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 1000 fpm (FPM)
Temperature Rating (°F): -40 °F to 180 °F

A503

2" Deep Light Duty Stainless Steel Backdraft Damper

A503

Maximum Velocity (FPM): 1000 fpm
Max Static Pressure: 1 .in w.g. @ 1000 fpm
Pressure Drop: .25 in. w.g. @ 1000 fpm

Material Options: 304 Stainless Steel, or 316 Stainless Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Pressure Drop: .25 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 1000 fpm (FPM)
Temperature Rating (°F): -40 °F to 180 °F

A580-BD

10" Deep Round Industrial Backdraft Damper

A580BD

Maximum Velocity (FPM): 6000 fpm
Max Static Pressure: 8 .in w.g. @ 1000 fpm
Pressure Drop: < .1 in. w.g. @ 1000 fpm

Material Options: 304 Stainless Steel, 316 Stainless Steel, or Fabricated Steel
Blade Type: Single Thickness Blade
Blade Action: Single
Frame Shape: Round
Pressure Drop: < .1 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 6000 fpm (FPM)
Temperature Rating (°F): 200 °F

AC580

Industrial Single Blade Round Control Damper

AC580

Maximum Velocity (FPM): 10000 fpm
Max Static Pressure: 12 .in w.g. @ 1000 fpm
Pressure Drop: < .1 in. w.g. @ 1000 fpm

Material Options: 304 Stainless Steel, 316 Stainless Steel, or Fabricated Steel
Blade Type: Single Thickness Blade
Blade Action: Single
Frame Shape: Round
Pressure Drop: < .1 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 10000 fpm (FPM)
Temperature Rating (°F): 250 °F

AC581

Industrial Heavy Duty Round Control Damper

AC580

Maximum Velocity (FPM): 10000 fpm
Max Static Pressure: 16 .in w.g. @ 1000 fpm
Pressure Drop: < .1 in. w.g. @ 1000 fpm

Material Options: 304 Stainless Steel, 316 Stainless Steel, or Fabricated Steel
Blade Type: Single Thickness Blade
Blade Action: Single
Frame Shape: Round
Pressure Drop: < .1 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 10000 fpm (FPM)
Temperature Rating (°F): 250 °F

BS55

4" Deep Extruded Aluminum Backdraft Damper

BS55

Maximum Velocity (FPM): 1000 fpm
Max Static Pressure: 4 .in w.g. @ 1000 fpm
Pressure Drop: .14 in. w.g. @ 1000 fpm

Material Options: Extruded Aluminum, or Extruded Aluminum 6063 Alloy
Blade Type: Single Thickness Blade
Blade Action: Parallel
Pressure Drop: .14 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 1000 fpm (FPM)
Temperature Rating (°F): -40 °F to 190 °F

AB1

5.5" Deep Single Thickness Blade Balancing Damper

AB1

Maximum Velocity (FPM): 2000 fpm
Max Static Pressure: 4 .in w.g. @ 1000 fpm
Pressure Drop: .04 in. w.g. @ 1000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Pressure Drop: .04 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Temperature Rating (°F): 200 °F

AB2

5.5" Deep Single Thickness Blade Balancing Damper

AB2

Maximum Velocity (FPM): 2000 fpm
Max Static Pressure: 4 .in w.g. @ 1000 fpm
Pressure Drop: .04 in. w.g. @ 1000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Opposed
Pressure Drop: .04 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Temperature Rating (°F): 200 °F

A1770

4" Deep Single Thickness Blade Steel Control Damper

A1770

Maximum Velocity (FPM): 2000 fpm
Max Static Pressure: 4 .in w.g. @ 1000 fpm
Pressure Drop: .037 in. w.g. @ 1000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel / Opposed
Pressure Drop: .037 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Temperature Rating (°F): -40 °F to 180 °F

128

2" Deep Single Blade Aluminum Damper

128

Maximum Velocity (FPM): 2000 fpm
Max Static Pressure: 1 .in w.g. @ 1000 fpm
Pressure Drop: .037 in. w.g. @ 1000 fpm

Material Options: Extruded Aluminum
Blade Type: Single Thickness Blade
Blade Action: Single
Pressure Drop: .037 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Temperature Rating (°F): -40 °F to 180 °F

AC530

Round Single Blade Control Damper with Seals

AC530

Maximum Velocity (FPM): 3000 fpm
Max Static Pressure: 6 .in w.g. @ 1000 fpm
Pressure Drop: .013 in. w.g. @ 1000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Single
Frame Shape: Round
Pressure Drop: .013 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 3000 fpm (FPM)
Temperature Rating (°F): 250 °F

S2 EP Series

Class II Single Thickness Blade Smoke Damper (EP Series)

S2H25034

Maximum Velocity (FPM): 3000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Frame Shape: Rectangular
Pressure Drop: .06 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 3000 fpm (FPM)
Temperature Rating (°F): 250 °F

S2(SS)

Class II Single Thickness Blade Stainless Steel Smoke Damper

S2H250SS

Maximum Velocity (FPM): 3000 fpm

Material Options: 304 Stainless Steel
Blade Type: Single Thickness Blade
Frame Shape: Rectangular
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 3000 fpm (FPM)
Temperature Rating (°F): 250 °F

FR2

Class II, 1.5 Hour Single Thickness Blade Mini Combination Fire-Smoke Damper

FR2H250, FR2H350, FR2V250, FR2V350

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .03 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F to 350 °F

FS2C

Class II 1.5 Hour Tunnel-Type Single Thickness Blade Combination Fire-Smoke Damper

FS2C250

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .06 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F

FS2C DAN Variant

Class II 1.5 Hour Tunnel-Type Single Thickness Blade Combination Fire-Smoke Damper

FS2C2G250

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .06 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F

MS19

1½ Hr. Rated Vertical Mount Non-Motorized Fire Damper

MS19V, MS19CV

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Frame Shape: Rectangular
Fire Resistance Rating (hrs): 1.5 hrs.

356-12

12" Deep Triple Deck Multi-Zone Galvanized Steel Damper

Maximum Velocity (FPM): 1000 fpm
Max Static Pressure: 2 .in w.g. @ 1000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Maximum Velocity (FPM): 1000 fpm (FPM)
Temperature Rating (°F): -20 °F to 140 °F

FS1GF ESB Series

Class I, 1.5 Hour Front Access Grille Combination Fire-Smoke Damper (ESB Series)

FS1HD250, FS1HD350, FS1VF250, FS1VF350

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .06 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F to 350 °F

FS1GF SSB Series

Class I, 1.5 Hour Front Access Grille Combination Fire-Smoke Damper (SSB Series)

FS1HE250, FS1HE350, FS1VG250, FS1VG350

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .06 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F to 350 °F

FS1

Class I 1.5 Hour Single Thickness Blade Combination Fire-Smoke Damper

FS1H250, FS1H350, FS1V250, FS1V350

Maximum Velocity (FPM): 3000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .06 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 3000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F to 350 °F

FS2C GCF Series

Class II 1.5 Hour Tunnel-Type Combination Fire-Smoke Damper (GCF Series)

FS2C2H250, FS2C2J250

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .06 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F

FS2 ECF Series

Class II 1.5 Hour Tunnel-Type Combination Fire-Smoke Damper (ECF Series)

FS2C2I250, FS2C2K250

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .06 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F

FS2

Class II 1.5 Hour Single Thickness Blade Combination Fire-Smoke Damper

FS2H250, FS2H350, FS2V250, FS2V350

Maximum Velocity (FPM): 3000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .06 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 3000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F to 350 °F

FS2GF ESB Series

Class II, 1.5 Hour Front Access Grille Combination Fire-Smoke Damper (ESB Series)

FS2HD250, FS2HD350, FS2VF250, FS2VF350

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .06 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F to 350 °F

FS2GF SSB Series

Class II, 1.5 Hour Front Access Grille Combination Fire-Smoke Damper (SSB Series)

FS2HE250, FS2HE350, FS2VG250, FS2VG350

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .06 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F to 350 °F

FT1

Class I, 3 Hour Single Thickness Blade Combination Fire-Smoke Damper

FT1H250, FT1H350, FT1V250, FT1V350

Maximum Velocity (FPM): 3000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .06 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 3000 fpm (FPM)
Fire Resistance Rating (hrs): 3 hrs.
Temperature Rating (°F): 250 °F to 350 °F

FT2

Class II, 3 Hour Single Thickness Blade Combination Fire-Smoke Damper

FT2H250, FT2H350, FT2V250, FT2V350

Maximum Velocity (FPM): 3000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .06 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 3000 fpm (FPM)
Fire Resistance Rating (hrs): 3 hrs.
Temperature Rating (°F): 250 °F to 350 °F

FR1

Class I, 1.5 Hour Single Thickness Blade Mini Combination Fire-Smoke Damper

FR1H250, FR1H350, FR1V250, FR1V350

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .03 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F to 350 °F

FS1(SS)

Class I 1.5 Hour Single Thickness Blade Stainless Steel Combination Fire-Smoke Damper

FS1H250SS, FS1V250SS

Maximum Velocity (FPM): 3000 fpm

Material Options: 304 Stainless Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .06 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 3000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F to 350 °F

FS2(SS)

Class II 1.5 Hour Single Thickness Blade Stainless Steel Combination Fire-Smoke Damper

FS2H250SS, FS2H350SS, FS2V250SS, FS2V350SS

Maximum Velocity (FPM): 3000 fpm

Material Options: 304 Stainless Steel, or 316 Stainless Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .06 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 3000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F to 350 °F

S1

Class I Single Thickness Blade Smoke Damper

S1H250, S1H350

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Frame Shape: Rectangular
Pressure Drop: .06 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Temperature Rating (°F): 250 °F to 350 °F

S1 EP Series

Class I Single Thickness Blade Smoke Damper (EP Series)

S1H25034

Maximum Velocity (FPM): 3000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Frame Shape: Rectangular
Pressure Drop: .06 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 3000 fpm (FPM)
Temperature Rating (°F): 250 °F to 350 °F

S1(SS)

Class I Single Thickness Blade Stainless Steel Smoke Damper

S1H250SS

Maximum Velocity (FPM): 3000 fpm

Material Options: 304 Stainless Steel
Blade Type: Single Thickness Blade
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 3000 fpm (FPM)
Temperature Rating (°F): 250 °F

S2

Class II Single Thickness Blade Smoke Damper

S2H250, S2H350

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Frame Shape: Rectangular
Pressure Drop: .06 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Temperature Rating (°F): 250 °F to 350 °F

SR1

Class I Single Thickness Blade Mini Smoke Damper

SR1H250, SR1H350, SR1V250, SR1V350

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .03 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Temperature Rating (°F): 250 °F to 350 °F

SR2

Class II Single Thickness Blade Mini Smoke Damper

SR2H250, SR2H350, SR2V250, SR2V350

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .03 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Temperature Rating (°F): 250 °F to 350 °F

MD39

3 Hour Rated Non-Motorized Single Thickness Blade Dynamic Fire Damper

MD39H, MD39V, MD39CH, MD39CV

Maximum Velocity (FPM): 4000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Maximum Velocity (FPM): 4000 fpm (FPM)
Fire Resistance Rating (hrs): 3 hrs.

MD19(SS)

1.5 Hour Rated Non-Motorized Stainless Steel Dynamic Fire Damper

MD19HSS, MD19VSS, MD19CHSS, MD19CVSS

Maximum Velocity (FPM): 2000 fpm

Material Options: 304 Stainless Steel, or 316 Stainless Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.

MD19(SS) HP Series

1.5 Hour Rated Non-Motorized Stainless Steel Dynamic Fire Damper (HP Series)

MD19HSS4, MD19VSS4, MD19CHSS4, MD19CVSS4

Maximum Velocity (FPM): 4000 fpm

Material Options: 304 Stainless Steel, or 316 Stainless Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Maximum Velocity (FPM): 4000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.

MD19

1.5 Hour Rated Non-Motorized Single Thickness Blade Dynamic Fire Damper

MD19H, MD19V, MD19CH, MD19CV

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Frame Shape: Rectangular
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
